HOME > Products > Low Bed Trailer Axle



MODEL PART NO. AXLE LOAD S/SEAT SPAN BRAKE SIZE INNER B.R.G OUTER R.R.G PITCH CIRCLE STUD HOLES WHEEL BORE DIA AXLE SHAFT WEIGHT
SWL-275A SW220-A0000 22,500Ibs (10.2TON) 1247

Φ311x190

 HM218248
/210		 HM212049
/011		 275mm 8HOLE 228.5mm

Φ127x19T

 309KG
SWL-275S SW220-A0000 22,500Ibs (10.2TON) 1247

Φ311x190

 HM218248
/210		 HM212049
/011		 275mm 8HOLE 228.5mm

Φ127x19T

 309KG
